Description
The RP054 from ISC is a 3/4" capacity spring block perfect for the working arborist. The upper sheave and pin are captured by the spring locking mechanism, eliminating the chance of dropping a sheave. The rope-friendly side plates are thick hot-forged aluminum with blue anodizing for a long-lasting finish.
Details
MBS: 150kN (33,720lbf)
WLL: 30kN (6,600lbf)
Length: 8-3/4" (225mm)
Width: 5.0" (125mm)
Thickness: 2.75" (70mm)
Weight: 3.5 lbs (2.2kg)
Sheave Diameter: 2.75" (70mm)
Maximum Rope Diameter: 3/4" (19mm)
Maximum Sling Diamater: 1 1/4" (32mm)
WLL: 30kN (6,600lbf)
Length: 8-3/4" (225mm)
Width: 5.0" (125mm)
Thickness: 2.75" (70mm)
Weight: 3.5 lbs (2.2kg)
Sheave Diameter: 2.75" (70mm)
Maximum Rope Diameter: 3/4" (19mm)
Maximum Sling Diamater: 1 1/4" (32mm)
CE Approved
- Manufacturer Part Number:
- RP055A1
- Country of Manufacture:
- GB
